Celto Acoustique 18'' 1200W Subwoofer [18SW1200-8]

Description

CELTO Acoustique 18SW1200-8 Loose Speaker

The SW series of subwoofers are the flagship of the CELTO range of loose bass transducers. There has been absolutely no compromise in design, selection of the materials used, manufacturing and the QC process.

The 18SW1200 is a beautifully finished ultra-thick powder coated aluminum die-cast woofer, with a solid <0.1% carbon CNC machined steel T-Yoke, French bobbin with Japanese wire 240°C voice coil, Japanese / USA damper, water resistant fiber loaded Canadian pulp paper cone, high grade Y35 flaw-free ferrite magnet and a robust 5mm square spring terminal connecting block.

Features

Long excursion, Low distortion design
Deep, clean and punchy bass
DCS (Deflective cooling system)
Water resistant Kevlar® loaded paper cone
Optimized parameters for compact cabinet designs

Specifications

Nominal diameter: 460mm (18″”)
Nominal impedance: 8 ohms
Power handling: 1200W RMS (AES Standard)
Sensitivity: 97dB / 1W / 1m
Voice coil diameter: 4 inch (100mm)
Voice coil height Hvc: 26mm
Voice coil air gap Hag: 12mm
Xmax (Hvc-Hag)/2 + Hag/4: +/- 10mm
Xmech (peak-peak): 50mm
Voice coil winding: 2 layer IN/OUT
Voice coil material: 240°C Thermal Class Copper
Voice coil former: DUPONT® GFB
Suspension: Triple roll, impregnated fabric
Spider: Dual with silicon damping, NOMEX®
Cone: Fiber loaded, waterproof treated paper

Chassis: Die-cast aluminum
Magnet: 220mm diameter Y35 ferrite

Mounting & Shipping

Overall Diameter: 470mm
Bolt circle diameter: 445mm
Baffle cutout diameter: 422mm
Flange & gasket thickness: 13mm
Overall depth: 212mm
Net weight: 13Kg
Shipping weight: 15Kg
Shipping dimensions: 460x460x280mm

T&S Parameters

F(s): 35Hz
Q(ms): 10.351
V(as): 205 liters
M(ms): 215 grams
R(ms): 4.568 Kg/s
S(d): 1225 sq.c+C5m
V(d): 1.225 liters
R(e): 5.7 ohms
Q(es): 0.427
C(ms): 0.0962 mm/N
Q(ts): 0.412
L(e): 1KHz: 1.98mH
BL: 25.1
n(0): 2.03%

Product form

CELTO Acoustique 18SW1200-8 Loose Speaker The SW series of subwoofers are the flagship of the CELTO range of loose bass... Read more

SKU: 2013925000000

R 3,945.00 Incl. VAT

Request a Quote

    • Guaranteed secure & safe checkout.
    • Free shipping on every order, no minimum required!
    • Over 20 years of professional experience
    • Pay securely afterwards with PayJustNow, PayFlex and PayFast
    Contact Us

    Have any questions? WhatsApp Us on 072 157 6825.

    Description

    CELTO Acoustique 18SW1200-8 Loose Speaker

    The SW series of subwoofers are the flagship of the CELTO range of loose bass transducers. There has been absolutely no compromise in design, selection of the materials used, manufacturing and the QC process.

    The 18SW1200 is a beautifully finished ultra-thick powder coated aluminum die-cast woofer, with a solid <0.1% carbon CNC machined steel T-Yoke, French bobbin with Japanese wire 240°C voice coil, Japanese / USA damper, water resistant fiber loaded Canadian pulp paper cone, high grade Y35 flaw-free ferrite magnet and a robust 5mm square spring terminal connecting block.

    Features

    Long excursion, Low distortion design
    Deep, clean and punchy bass
    DCS (Deflective cooling system)
    Water resistant Kevlar® loaded paper cone
    Optimized parameters for compact cabinet designs

    Specifications

    Nominal diameter: 460mm (18″”)
    Nominal impedance: 8 ohms
    Power handling: 1200W RMS (AES Standard)
    Sensitivity: 97dB / 1W / 1m
    Voice coil diameter: 4 inch (100mm)
    Voice coil height Hvc: 26mm
    Voice coil air gap Hag: 12mm
    Xmax (Hvc-Hag)/2 + Hag/4: +/- 10mm
    Xmech (peak-peak): 50mm
    Voice coil winding: 2 layer IN/OUT
    Voice coil material: 240°C Thermal Class Copper
    Voice coil former: DUPONT® GFB
    Suspension: Triple roll, impregnated fabric
    Spider: Dual with silicon damping, NOMEX®
    Cone: Fiber loaded, waterproof treated paper

    Chassis: Die-cast aluminum
    Magnet: 220mm diameter Y35 ferrite

    Mounting & Shipping

    Overall Diameter: 470mm
    Bolt circle diameter: 445mm
    Baffle cutout diameter: 422mm
    Flange & gasket thickness: 13mm
    Overall depth: 212mm
    Net weight: 13Kg
    Shipping weight: 15Kg
    Shipping dimensions: 460x460x280mm

    T&S Parameters

    F(s): 35Hz
    Q(ms): 10.351
    V(as): 205 liters
    M(ms): 215 grams
    R(ms): 4.568 Kg/s
    S(d): 1225 sq.c+C5m
    V(d): 1.225 liters
    R(e): 5.7 ohms
    Q(es): 0.427
    C(ms): 0.0962 mm/N
    Q(ts): 0.412
    L(e): 1KHz: 1.98mH
    BL: 25.1
    n(0): 2.03%
